Industrial Working Automatic Robotic Arm Arc Welding Robot 2036mm Reach With 6kg Payload

Name: Industrial Working Automatic Robotic Arm Arc Welding Robot 2036mm Reach With 6kg Payload
Brand: KAWASAKI
Price: 1 USD

Brand Name : KAWASAKI

Model Number : BA006L

Certification : CE

Place of Origin : China

MOQ : 1 set

Payment Terms : T/T, L/C, Western Union

Supply Ability : 50 sets /Month

Delivery Time : 7 working days after deposit

Packaging Details : One Working robot and industrial robot hand max. payload 6kg reach 2036mm BA006L robot arm for weld for kawasaki packing with fumigation wooden frame, WG: 1120 KG Controller and other parts packing with brown box, WG: 120 KG

Product name : Working robot and industrial robot hand max. payload 6kg reach 2036mm BA006L robot arm for weld for kawasaki

Model : BA006L-A

Type : Articulated robot

Axis : 6

Payload : 6kg

Reach : 2036mm

Mass : 160kg

Speed : 14800mm/s

Color : Munsell 10GY9/1 equivalent

Relative humidity : Max. 95 %

Contact Now

Working robot and industrial robot hand max. payload 6kg

reach 2036mm BA006L robot arm for weld for kawasaki

Specification

Type	Articulated Robot
Degrees of Freedom	6
Payload (kg)	6
Max. Reach (mm)	1,445
Positional Repeatability (mm)	±0.06
Motion Range (°)	Arm Rotation (JT1)	±165
	Arm Out-in (JT2)	+150 - −90
	Arm Up-down (JT3)	+90 - −175
	Wrist Swivel (JT4)	±180
	Wrist Bend (JT5)	±135
	Wrist Twist (JT6)	±360
Max. Speed (°/s)	Arm Rotation (JT1)	240
	Arm Out-in (JT2)	240
	Arm Up-down (JT3)	220
	Wrist Swivel (JT4)	430
	Wrist Bend (JT5)	430
	Wrist Twist (JT6)	650
Allowable Moment (N•m)	Wrist Swivel (JT4)	12
	Wrist Bend (JT5)	12
	Wrist Twist (JT6)	3.75
Allowable Moment of Inertia (kg•m2)	Wrist Swivel (JT4)	0.4
	Wrist Bend (JT5)	0.4
	Wrist Twist (JT6)	0.07
Mass (kg)	150
Mounting	Floor, Ceiling
Installation Environment	Ambient Temperature (°C)	0 - 45
	Relative Humidity (%)	35 - 85 (No dew, nor frost allowed)
Controller / Power Requirements (kVA)	America	E01 / 5.6
	Europe
	Japan & Asia

Product Description

BA006L Robot

THROUGH-ARM CABLE ARC WELDING ROBOTS

The BA006L arc welding robot has a maximum reach of 2,036 mm and a hollow wrist structure that allows for easy management of cables and hoses around the torch, providing stable wire feeding and reliable offline teaching.
